Custom Natural Silk Coated Litz Wire For 0.1mmx80

Name: Custom Natural Silk Coated Litz Wire For 01mmx80
Brand: Ruiyuan
Price: 1 USD

Brand Name : Ruiyuan

Model Number : USTCF litz wire

Certification : UL/ISO9001/ISO14001/RoHS/Reach

Place of Origin : China

MOQ : 10kg

Price : Negotiation

Payment Terms : TT/Paypal

Supply Ability : 100kg/week

Delivery Time : 7 days

Packaging Details : Carton

Single Wire : 0.1mm

Number Of Strands : 80

Jacket : Natural silk

Other option of Jackets : Polyester, Nylon

Conductor Material : Copper

Key word : 0.1mmx80 Multiple Strands Real Silk Covered Litz WireCustom Natural Silk Coated Litz Wire For 0.1mmx80

Product name : Custom Natural Silk Coated Litz Wire For 0.1mmx80

Contact Now

Custom Natural Silk Coated Litz Wire For 0.1mmx80

Our custom high-frequency Silk ocvered Litz wire represents the pinnacle of audio engineering and craftsmanship. Featuring a natural silk outer layer, 80-strand enameled copper wire, and small-batch customization options, this wire is designed for those who refuse to compromise on quality.

Type Conductor diameter*Strand number			2USTC-F 0.10*80
Single wire(strand)	Conductor diameter(mm)		0.100±0.003
	overall diameter (mm)		0.107-0.125
	Thermal Class(℃)		155
Strands construction	Strands number		80
	Pitch(mm)		29±5
	bunching direction		S
Insulation layer	Material type		Natural silk
	Material specs(mm*mm or D)		300
	Times of Wrapping		1
	Overlap(%) or thickness(mm),mini		0.02
	Wrapping direction		S
Characteristics	Overall Diameter	Nominal (mm)	1.20
		Max(mm)	1.28
	Max pinholes Faults/6m		40
	Max resistance (Ω/Km at20℃)		29.76
	Breakdown voltage Mini (V)		1100
